Nexthor Aegis™ Paint Protection Film
Matte Carbon Fiber SelfRepair Nano-Coated PPF
Matte Carbon Fiber SelfRepair Nano-Coated PPF - Black Carbon / 15 m ist auf Lager und wird versandt, sobald es wieder verfügbar ist
Width: 1.52 m
Verfügbarkeit für Abholungen konnte nicht geladen werden
Description
Description
Matte Carbon Fiber Self-Healing PPF: Stealth Protection with a Carbon Fiber Finish
This 7.5 mil self-healing paint protection film shields your car's surface from rock chips, scratches, UV damage, and road debris. The Matte Carbon Fiber finish delivers a stealthy carbon-inspired texture with a smooth matte appearance that enhances any vehicle with a motorsport-driven look. The TPU film absorbs impacts that would otherwise damage factory paint while preserving the refined depth and texture of the carbon fiber design.
SelfRepair™ Technology Erases Minor Damage
Nexthor SelfRepair™ topcoat responds to heat, erasing light scratches and swirl marks within minutes. Park in the sun or rinse with warm water, and the film's surface restores itself to a smooth, flawless matte finish. This self-healing paint protection film keeps your Matte Carbon Fiber PPF looking clean and sharp without constant correction or maintenance.
AquaGuard™ Hydrophilic Nano Coating and BondGrip™ Adhesive
The German-engineered AquaGuard™ hydrophilic nano coating spreads water into a thin sheet that carries dirt and contaminants off the surface. This hydrophilic coating keeps your carbon fiber PPF cleaner between washes and requires no reapplication. BondGrip™ adhesive locks the film to your paint with a secure, bubble-free bond. Backed by a 10-year warranty, this Matte Carbon Fiber paint protection film is built to last.
Order Matte Carbon Fiber Self-Healing Nano-Coated PPF today and give your car a stealth-inspired carbon finish with long-lasting protection.
Color & Effect
Color & Effect
Performance & Protection
Performance & Protection
Performance & Protection
Nexthor™ PPF is engineered as a next-generation multilayer aliphatic TPU protection system optimized for impact resistance, optical clarity, and controlled elasticity at optimized thickness.
| Multilayer Architecture | |
|---|---|
| Nano-Coating | Hydrophilic surface layer engineered for long-term optical stability. |
| Self-Healing Topcoat | Heat-activated surface recovery designed for daily-use micro-marring. |
| Aliphatic TPU Core | High-strength core engineered for impact resistance and stretch stability. |
| Acrylic PSA Adhesive | Optically clear pressure-sensitive adhesive for controlled tack and edge hold. |
| Double-Matte Release Liner | Controlled release and dimensional stability during installation. |
| Core Performance Targets | |
|---|---|
| Optical clarity | Engineered for a clean, distortion-minimized finish under real-world lighting. |
| Impact resistance | Designed to absorb and disperse stone-strike energy through the TPU core. |
| Elastic control | Balanced conformability for complex panels with stable shrink behavior. |
| Hydrophobic top surface | Low surface energy to reduce contamination bonding and improve washability. |
| Self-repair response | Heat-responsive polymer memory restores surface from light micro-scratches. |
| Warranty Coverage (Material) | |
|---|---|
| Term | 10-year material warranty |
| Coverage | Yellowing protection · crack & blister coverage · delamination protection · adhesive failure protection |
For full measured values and tolerances, use the Technical Specifications tab.
Technical Specifications
Technical Specifications
| Nexthor™ Paint Protection Film – Technical Specifications (AEGIS™ Mk I – 7.5 mil) | |
|---|---|
| Optical & Surface | |
| Gloss (60°) | ≥ 94% |
| Water Contact Angle | ≥ 103° |
| Anti-Fouling | Strongest marker (pass) |
| Yellowness Index | ≤ 2 |
| Mechanical Performance | |
| Tensile Strength | ≥ 360 kg/cm² |
| Elongation at Break | ≥ 350% |
| Peel Strength | ≥ 75 N/cm |
| Shrinkage (MD) | ≤ 0.5 mm |
| Shrinkage (TD) | ≤ 0.4 mm |
| Material Structure | |
| Total Thickness | 180 ± 5 μm |
| TPU Layer Thickness | 150 ± 5 μm |
| Coating Thickness | 10 ± 5 μm |
| Adhesive Thickness | 20 ± 5 μm |
| Liner Thickness | 75 ± 5 μm |
| Layer Thickness | 50 ± 5 μm |
| Finished Weight | 375–395 g/m² |
| Glue Weight | 25–30 g/m² |
| Appearance Quality | |
| Liner Bubbles | Visually invisible |
| Dust | Visually invisible |
| Coated Dump | Visually invisible |
| Glue Line | Visually invisible |
| Crystal Points (12.7 × 12.7 cm) – 0.1–0.6 mm | Allowed |
| Crystal Points (12.7 × 12.7 cm) – 0.7–2.9 mm | < 10 |
| Crystal Points (12.7 × 12.7 cm) – ≥ 3.0 mm | 1 max |
| Adhesion System | |
| Adhesive Type | Optically clear acrylic PSA |
| Tack | ≥ 9 N / 25 mm |
| 24h, 180° Peel | ≥ 18 N / 25 mm |
| Release Force | ≤ 0.35 N / 25 mm |
| Thermal Resistance | |
| Maximum Temperature | 120°C (≥ 5 min) |
| Self-Repair Activation Range | 60–80°C |
| Self-Repair Technology | |
| Self-Healing | Heat 75°C, 0.1 mm (Brush & Heat) |
| Chemical Resistance | |
| Acid & Alkali Resistance | PASS |
| Anti-Acid | Oxalate 72 (pass) |
| Storage & Warranty | |
| Recommended Storage | 22°C ± 2°C | 40–60% RH | store upright in original packaging, away from UV & heat |
| Shelf Life | 12 months (stored upright in original packaging at 15–25°C and ~50% RH) |
| Material Warranty | 10-year material warranty |
| Warranty Coverage | Yellowing protection, crack & blister coverage, delamination protection, adhesive failure protection |
Protection Package
Protection Package
Precision outside. Innovation inside. Structured to maintain film integrity during handling and movement. Designed to reduce unnecessary stress, bending, and surface exposure before application.
Engineered to support stable transport, clean handling, and precise installation conditions.
Application & Installation
Application & Installation
Nexthor™ Paint Protection Film is manufactured from premium American and German raw materials and engineered for maximum tensile strength, optical clarity, and controlled elasticity at optimized thickness. Correct installation ensures full adhesive activation, structural integrity, and long-term performance.
Professional Requirements
Installation must be performed in a controlled, dust-free environment using professional-grade tools. Surface contamination, improper slip ratios, or uncontrolled heat application may compromise adhesion performance.
- Professional PPF squeegee (multi-hardness)
- Precision blade system
- Lint-free microfiber system
- Distilled water only
- Heat control equipment
Installation Methodology
Nexthor™ PPF is designed for precision wet application using controlled alignment, calibrated slip ratios, and structured adhesive activation. The following methodology ensures optimal bonding strength, visual clarity, and long-term durability.
1. Surface ConditioningVehicle surface must be fully decontaminated and panel temperature stabilized. Final wipe with isopropyl alcohol solution is mandatory. Surface must be clean, dry, oil-free, and dust-free.
2. Slip FormulaRecommended ratio: 1L distilled water + 2–4 drops pure baby shampoo. Mix gently to maintain low-foam consistency. No conditioners, waxes, or silicone-based additives permitted.
3. Film PositioningApply slip solution to both surface and adhesive layer. Position film under controlled tension. Maintain alignment with body lines and structural reference points.
4. Adhesive ActivationExecute center-out squeegee passes with overlapping pressure lines. All fluid must be evacuated to achieve full adhesive contact. Edges must be secured using controlled pressure and temperature. Avoid overheating.
5. Curing Phase
Initial bond stabilization: 24 hours.
Complete adhesive cure: 7–30 days depending on climate conditions.
During curing:
No washing for 48 hours.
No high-pressure exposure for 7 days.
Temporary moisture pockets may appear and will dissipate naturally.
Maintenance & Care
Nexthor™ PPF incorporates advanced self-healing elastomer technology activated by thermal energy. Wash with pH-neutral automotive shampoo only. Avoid abrasive tools and aggressive chemical exposure. Professional installation is strongly recommended for complex geometries and high-tension panels.
For the complete step-by-step documentation, technical notes, and extended installer guidance, please review the full Installation Guide:
View Full Nexthor™ Installation Guide
